General view basic setup VACUU•LAN
connect cooling
water valve
setting process parameters
➨ pressure value (condition for automatic shut down)
➨ upper set point (condition for restart)
➨ time for automatic shut down
setting the basic setup
basic setup VACUU•LAN
yes
no
switching cooling
water valve?
start: pump down
☞☞
☞☞
☞ The pump (and the cooling water valve if applicable) is
switched off if the pressure is below the lower pressure
value longer than the time for automatic shut down.
☞☞
☞☞
☞ The pump starts automatically if the pressure is higher
than the upper set point.
