vacuubrand CVC 2 - Basic Setup Overview; Standard, Management, Management Plus, VACUU•LAN

page 9 of 36
Documents are only to be used and distributed completely and unchanged. It is strictly the users´ responsibility to check
carefully the validity of this document with respect to his product. manual-no.: 99 90 20 / 01/12/2004
setting pressure unit (mbar / Torr / hPa)
configuration of the cooling water valve if applicable
automatic identification of the solenoid operated isolation valve
setting basic setup
ready to
start
basic setup ”Standard” (factory-set)
controller switches
- solenoid operated isolation valve (indispensable)
- cooling water valve (optional)
basic setup ”Management”*
controller switches
- pump
- solenoid operated isolation valve if connected
- cooling water valve (optional)
basic setup ”VACUU•LAN”*
controller switches
- pump according to preset pressure and time
values
- solenoid operated isolation valve if connected
* only in combination with Vacuum-Management-
System VMS Module A
basic setup ”Management Plus” *
controller switches
- pump, but with after-running to pump out condensate
- solenoid operated isolation valve (indispensable)
- cooling water valve (optional)
General view basic setups
CVC 2
II
