Safety instructions:
! Note: The placement of the device should be done by a licensed electrician journeyman
burners .
! Caution : This device is designed for installations electricity 230Volts AC/50Hz. Make
sure the power supply is interrupted before connecting the device and when for any rea-
son remove the plastic front cover and is mounted on the wall or in a box rail .
! Caution : This product should not be used in critical applications for human life. If the
product does not work as directed by the manufacturer consult the service department of
the manufacturing company (0030 210 2323345 ) .
Installing Installation:
The V-DCS3 device is enclosed in a box DIN RAIL BOX 6 fuses and can be mounted on
top hat rail box, table rail (see page 9) or directly on the wall.
The space that the device is positioned V-DCS3 should not wetted or not has a high mois-
ture level .
External cables connecting the power supply and signal cables is not necessary to cross to
exceed 1mm 2x1mm.
The cables connect the sensors of the device is not necessary that the cross-section not
exceed 0,50 mm 2x0, 50mm.
! Caution : The sensor cables should not be combined with power cords power and the
maximum length of these should not exceed 50m.
It is not necessary to open the device as you may create irreparable damage to electronic
circuits. The connection terminals are accessible immediately.
Specifications
Area Imaging Sensors & Setup Con-
trollers
-10,0 ⁰ C till +150,0 ⁰ C with a pitch 1 ⁰ C
Setting Precision Sensors Adjustable -3,0 ⁰ C to +3,0 ⁰ C with a pitch 1 ⁰ C.
dimensions
Power Supply ~ 230V AC/50Hz ± 10%
Resistance relay contacts 6A / 250 VAC
remote sensors Extension to 50 meters (V-KTYxxx)
temperature Operation -10,0 ⁰ C to +50,0 ⁰ C
