11Installation and maintenance manual ecoLEVEL GB
Customer service 10
Technical data 11
10 Customer service
Vaillant customer service
To ensure regular servicing, it is strongly recommended
that arrangements are made for a Maintenance
Agreement. Please contact Vaillant Service Solutions
(0870 6060 777) for further details.
11 Technical data
Technical data Units ecoLEVEL
Design Appliance for wall-mounted installation
Nominal capacity l 0,5
Mains voltage V 230
Max. current consumption A 1
Frequency Hz 50
Max. power rating W 22
Max. pump head m 4
Volume flow l/h 150
Dimensions Height mm 160
Width mm 180
Depth mm 100
Weight when filled with water kg 1,8
Feed hose (max. outside diameter) mm 24
Discharge hose (min. inside diameter) mm 10
Water infeed temperature °C 1 ... 60
Ambient temperature °C 5 ... 60
Safety Radio-shielded, non-interacting with the mains supply
Overflow circuit breaker 5 mA ...4 A; 230 V
Level of protection according to EN 60529 IP 44
Table 11.1 Technical data
