Subject to alteration 43
Main component 06 Heat exchanger
VC 110,180,240 T, VCW 240,280 T
Pict.
No.
Article-No. Part Indic. Type, Remarks
1 06-1849 heat exchanger 110
06-1835 heat exchanger 180
06-1836 heat exchanger 240
06-1872 heat exchanger 280
2 98-1511 packingring
3 17-7511 de-aeration screw supplied with part 4
4 98-2459 packingring
5 10-1462 temperature limiter
6 13-3908 screw
7 11-8335 combustion chamber 110
11-8463 combustion chamber 180
11-8465 combustion chamber 240
11-8467 combustion chamber 280
8-9 - single delivery not possible see pict.-nr. 7
10 08-8624 screw
11 07-9415 guide plate 110 right
07-9416 guide plate 110 left
07-9407 air duct 180
07-9405 air duct 240,280
12 08-4937 connection piece 180
08-4936 connection piece 240
08-4953 connection piece 280
13 23-5727 screw
14 - connection see main component 08
15 - heat exchanger (DHW) replaced by, 06-5034 see page 50 + 51
16 98-1602 packingring
17 98-1609 packingring
18 08-4939 connection piece 110
19 08-9572 connection line
20 08-9571 connection line
21 15-3396 guide plate only 280
22 16-1225 inspection glass
23 13-1813 frame for inspection glass
supplied with parts 2-4
only 110
supplied with parts 8,9
VCW only
