Main component 04 Burner
VC 112 E H,B
Pict.
No.
Article-No. Part Indic. Type, Remarks
H = Natural gas, B = LP-gas
1 18-3974 distributor tube supplied with part 28
2 24-7140 burner nozzle Ø 1,40 H
24-7078 burner nozzle Ø 0,78 B
3 04-0467 burner chamber group
4 09-0649 monitoring electrode right
5 - ignition electrode replaced by pict.-no. 25-27, 09-0673
6 09-1513 ignition wire
7 13-9203 screw
8 09-0034 safety disc
9 13-3936 screw
10 98-2481 packingring B
11 04-9601 throttle jet Ø 3,05 B
12 98-2495 packingring
13 - connection parts see main component 08
14 23-5728 screw
15 10-5758 screw
16 23-5727 screw
17 08-8932 flow switch connection
18 04-0364 nut
19 98-1805 packingring
20 08-1063 connection
21 08-0369 hose 250 mm
22 13-3504 nipple
23 13-3505 nipple
24 08-8936 flow switch connection
25-27 09-0673 ignition electrode left (supplied with part 6)
28 08-5859 support
29 25-5928 cable tree
