Vaillant thermocompact vu 182/1 e - Heat Exchanger

Subject to alteration 45
Main component 06 Heat exchanger
VC 112,182,242,282 E, VCW 242,282 E
Pict.
No.
Article-No. Part Indic. Type, Remarks
1 06-1849 heat exchanger 112
06-1835 heat exchanger 182
06-1836 heat exchanger 242
06-1872 heat exchanger 282
2 - packingring see main component 08
3 17-7511 de-aeration screw supplied with part 4
4 98-2459 packingring
5 10-1384 temperature limiter 112
10-1392 temperature limiter 182
10-1391 temperature limiter 242,282
6 08-4939 connection piece 112
08-4942 connection piece 182
08-4941 connection piece 242
08-4959 connection piece 282
7 11-8335 combustion chamber 112
11-8464 combustion chamber 182
11-8466 combustion chamber 242
11-8468 combustion chamber 282
8-9 - single delivery not possible see pict.-nr. 7
10 08-8624 screw 3,5 + 4,8 x 9,5
11 07-9415 guide plate right
07-9416 guide plate left
12 - not necessary
13 23-5727 screw
14 - connection tube see main component 08
15 - heat exchanger (DHW) replaced by, 06-4953 see page 50 + 51
16 98-1602 packingring
17 98-1609 packingring
18 - not necessary
supplied with parts 2-4
only VC 112
supplied with parts 8,9
VCW only
