Main component 07 Casing parts
VC 180,240 T, VCW 240,280 T
Pict.
No.
Article-No. Part Indic. Type, Remarks
1 - chassis not available as a spare part
2 15-4220 bow
3 15-4227 bow
4 08-6322 support
5 23-5727 screw
6 07-0357 nut
7 98-0093 packingring
8 06-0020 disc
9 07-0350 screw
10 23-5737 screw
11 14-9627 support 180
14-9628 support 240,280
12 21-3362 back panel
13 13-9203 screw
14 11-6477 screw
15 22-1723 support
16 12-6153 spring
17 07-4920 draft diverter 180
07-4921 draft diverter 240
07-4940 draft diverter 280
18 07-5461 covering plate
19 13-3799 screw M 8 x 4 knurled
23-5715 screw 4,8 x 9,5 sheet metal (from 04/95)
20 07-1472 push button
21 07-9920 lateral panel right supplied with parts 9,22-27
22-27 08-8620 fastening set supplied with part 28
28 07-0351 screw
29 07-9921 lateral panel left
30 29-4012 top door 180,240 (supplied with parts 32-35)
29-4030 top door 280 (supplied with parts 32-37)
31 29-4013 bottom door supplied with parts 32-35
32 17-0356 door magnet only for 180,240 (slide on version from 04/95)
07-0355 door magnet 280 (screwed type)
33 15-8207 nut
34 23-5748 screw
35 12-4870 bush
36 21-3377 back panel
37 23-5748 screw
38 15-3375 guide plate
39 08-8215 flue adaptor 180
08-8216 flue adaptor 240
08-8214 flue adaptor 280
Timer assembly, acc.-no. 2378054
- 2370102 covering plate
- 2370099 time clock black plastic spring clips are seperate
- 2370100 wiring harness
only for 280
not shown
