Subject to alteration 87
Main component 08 Acc.-connection parts
VC 110-282, VCW 180-282
Pict.
No.
Article-No. Part Indic. Type, Remarks
1 08-0177 nut
2 08-0184 brass olive
3 95-0272 nut
4 08-1714 cold water connection supplied with parts 5,6
5 98-1605 packingring
6 95-0057 upper part of valve
7 14-3981 knob
8 - no more available see pict.-no. 6
9 98-1508 packingring
10 98-1511 packingring
11 98-0410 packingring
12 11-1328 sleeve nut
13 98-2459 packingring
14 14-0015 de-aeration screw
15 19-0721 pressure relief valve
16 - - not available as spare part see acc.-no. 9326 or 9327
see acc.-no. 9326 (return) or 9327 (flow)
17 08-0945 water connection
18 08-1144 water connection
19 08-0537 nut
Note:
Connetion complete VC... acc.-no. 009745
VCW... acc.-no. 009313
