Subject to alteration 11
Main component 01 Water valve, Servo control valve (to 04/95)
VCW 221, 240,280 T, 242,282 E
Pict.
No.
Article-No. Part Indic. Type, Remarks
1a - water valve, cpl. A VCW 221,240,280 T
VCW 242 E
- water valve, cpl. B VCW 280 T, 282 E
1b 01-1156 water valve, cpl. VCW 242 E (supplied with parts 2-7,14,15,21-27)
2 01-3014 top section supplied with parts 3,4
3 98-1506 packingring
4 01-2156 stuffing box green inset
5 98-1506 packingring
6 01-0050 screw
7 01-0003 diaphragm screw
8 10-4263 spring
9 01-0007 diaphragm disc
10 01-0312 diaphragm
11 01-2944 water quantity regulator
12 10-4267 spring
13 01-0020 venturi ø 3,32 for type A
01-0021 venturi ø 3,53 for type B
14 01-2629 overpressure valve
15 01-0053 water filter
16 01-2533 temperature selector for type A
01-2534 temperature selector for type B
17 98-0305 packingring
18 98-0149 o-ring
19 12-5117 handle
20 10-5744 screw
21 98-1511 packingring
22 98-1755 packingring
23 01-0009 spring
24 19-1367 disc
25 01-0426 diaphragm disc
26 01-0318 diaphragm
27 08-8617 fastening set
28 01-2938 water quantity regulator only for type 1b
see execution from 05/95 page 15
only for water valves with distinctive
mark " + " upon underside of part (see inset diagram)
supplied with parts 17,18
