Subject to alteration 15
Main component 01 Water valve, Servo control valve (from 05/95)
VCW 221, 240,280 T, 242,282 E
Pict.
No.
Article-No. Part Indic. Type, Remarks
1 01-1267 water valve 221,240 T,242 E (with parts 2-9,11-14,16-22)
01-1251 water valve 280 T,282 E (with parts 2-9,11-14,16-22)
2 01-3056 upper part
3 01-0359 diaphragm set with part 5 (5 x pieces)
4-not necessary for british execution
5 11-8959 screw
6 01-2553 temperature selector 221,240,242
01-2554 temperature selector 280,282
7 98-2497 packingring
8 12-5117 handle
9 10-5744 screw
10 -
not necessary for british execution
11 10-9918 plug
12 98-2484 packingring
13 01-2954 water quantity regulator
14 98-0287 packingring
15 -
not necessary for british execution
16 98-1506 packingring
17 01-2629 overpressure valve
18 01-0050 screw
19 01-2854 venturi ø 2,10 221,240,242
01-2819 venturi ø 2,80 280,282
20 12-8516 water filter
21 98-0197 packingring
22 98-0186 packingring
