Main component 01 Hydraulically controlled diverter valve
VCW 221, 240,280 T, 242,282 E
Pict.
No.
Article-No. Part Indic. Type, Remarks
1 01-2684 diverter valve supplied with parts 2-15,17
2 01-0003 diaphragm screw
3 10-4244 spring
4 02-0630 valve disc
5 98-2488 packingring
6 98-1518 packingring
7 01-2140 stuffing box
8 01-0457 diaphragm disc
9 01-0337 diaphragm
10 01-0421 diaphragm disc
11 01-2141 stuffing box
12 12-6233 micro-switch
13 10-5760 screw
14 20-5521 cap
15 98-1511 packingring
16-16a 15-5614 screw
17 98-1898 packingring
18 08-4245 flow switch connection
19 08-8940 flow switch connection
20 13-6313 nipple
21 - connection piping see main component 08
22 - bracket single delivery not possible, with spare part 01-2684
23 - microswitch bracket single delivery not possible, with spare part 12-6233
