Main component 04 Burner
VC 142 E H,B
Pict.
No.
Article-No. Part Indic. Type, Remarks
H = Natural gas, B = LP-gas
1 18-3905 distributor tube
2 24-7140 burner nozzle Ø 1,40 H
24-7078 burner nozzle Ø 0,78 B
3 04-1920 burner chamber group
4 09-0649 monitoring electrode right
5 06-0018 screw
6 09-0034 safety disc
7 09-0673 ignition electrode left (supplied with part 6)
8 09-1513 ignition wire
9 13-3936 screw
10 98-2495 packingring
12 08-5859 support
13 10-5758 screw
14 23-5727 screw
15 08-8946 flow switch connection
16 04-0364 nut
17 98-1805 packingring
18 08-1063 connection
19 08-0369 hose
20 13-3504 nipple
21 13-3505 nipple
22 08-8947 flow switch connection
23 98-2481 packingring B
24 04-9608 throttle jet Ø 3,25 B
31 08-4945 connection piece
32 25-5928 cable tree
