Subject to alteration 29
Main component 04 Burner, Pilotburner
VC 180,240 T, VCW 240,280 T H,B
Pict.
No.
Article-No. Part Indic. Type, Remarks
S = town gas, H = Natural gas, B = LP-gas
1 18-3968 distributor tube 180
18-3969 distributor tube 240,280
2 24-7260 burner nozzle Ø 2,60 S
24-7150 burner nozzle Ø 1,50 H
24-7080 burner nozzle Ø 0,80 B
3 04-0467 burner chamber group 180
04-0468 burner chamber group 240,280
6 06-0018 screw
8 04-2951 pilot burner support supplied with parts 6,11
11 09-0643 ignition electrode
12 04-2876 pilot burner nozzle Ø 0,45 S
04-2864 pilot burner nozzle Ø 0,30 H
04-2874 pilot burner nozzle Ø 0,18 B
13 17-1165 thermo-couple
14 04-3931 pilot burner tube
17 13-3936 screw
18 08-4957 connection piece
19 98-2495 packingring
20 98-2481 packingring B
21 04-9604 throttle jet Ø 3,40 180 B
04-9603 throttle jet Ø 4,00 240 B
04-9612 throttle jet 3 x Ø 3,50 280 B
22 98-1512 packingring
23 23-5727 screw
24 10-5758 screw
25 23-5728 screw
26 09-1060 piezo ignition lead attached to piezo ignition unit, not available seperatley
