Subject to alteration 31
Main component 04 Burner, Pilotburner
VC-VCW 221 T H,B
Pict.
No.
Article-No. Part Indic. Type, Remarks
S = town gas, H = Natural gas, B = LP-gas
1 18-3973 distributor tube
2 24-7130 burner nozzle Ø 1,30 H
24-7078 burner nozzle Ø 0,78 B
3 04-0468 burner chamber group
4 04-2968 pilot burner support supplied with parts 5,6
5 09-0658 ignition electrode
6 13-9201 screw
7 04-2876 pilot burner nozzle Ø 0,45 S
04-2864 pilot burner nozzle Ø 0,30 H
04-2874 pilot burner nozzle Ø 0,18 B
8 04-3939 pilot burner tube
9 - thermo-couple old execution, see pict.-no. 35 (new) replaced by 17-1181
10 13-3936 screw
11 08-4944 connection piece
12 98-2495 packingring
13 98-2481 packingring B
14 04-9607 throttle jet Ø 3,70 B
15 98-1512 packingring
16 10-5758 screw
17 23-5727 screw
18 23-5728 screw
19 98-1805 packingring
20 04-0364 nut
21 13-3504 nipple
22 13-3505 nipple
23 08-8949 flow switch connection
24 08-8930 flow switch connection
25 08-3891 tube
26 98-2499 packingring
27 08-1063 connection
28 98-0202 packingring
29 11-4848 nut
30 08-0369 hose 250 mm diaphragm pump
31 98-0765 packingring
32 07-0881 cover plate supplied with parts 33,34
33 06-0021 disc
34 23-5715 screw
35 17-1181 thermo-couple
