Main component 04 Burner
VC 182,242,282 E, VCW 242,282 E H,B
Pict.
No.
Article-No. Part Indic. Type, Remarks
S = town gas, H = Natural gas, B = LP-gas
1 18-3972 distributor tube 182
18-3973 distributor tube 242,282
2 24-7260 burner nozzle Ø 2,60 S
24-7140 burner nozzle Ø 1,40 H
24-7078 burner nozzle Ø 0,78 B
3 04-0467 burner chamber group 182
04-0468 burner chamber group 242,282
4 09-0649 monitoring electrode right
6 13-9203 screw
7 09-0034 safety disc
8 13-3936 screw
9 08-4944 connection piece supplied with part 10
10 98-2495 packingring
11 98-2481 packingring B
12 04-9604 throttle jet Ø 3,40 182 B
04-9603 throttle jet Ø 4,00 242 B
04-9610 throttle jet 2x Ø 3,10 282 B
13 98-1512 packingring
14 23-5727 screw
15 10-5758 screw
16 23-5728 screw
17 98-1805 packingring
18 04-0364 nut
19 13-3504 nipple
20 13-3505 nipple
21 08-8949 flow switch connection
22 07-0881 cover plate
23 06-0021 disc
24 23-5715 screw
25 08-8930 flow switch connection
26 09-1513 ignition wire
27 08-3891 tube
28 98-2499 packingring
29 08-1063 connection
30 98-0202 packingring
31 11-4848 nut
32 08-0369 hose 250 mm
33 98-0765 packingring
34-36 09-0673 ignition electrode left (supplied with part 26)
37 25-5928 cable tree VC...
25-5929 cable tree VCW...
