Vaillant time SWITCH 110 - Setting the Heating Programme

4 Programming heating periods
8
GB
4.1 Setting the tappets
Set the tappets (5a) and (5b) as follows:
For heating on periods press the tappets (5a)
inwards.
For heating off periods press the tappets (5b) out-
wards.
4.2 Setting the heating programme
Open the inspection window of the timer. Set the
tappets (4) and (5) according for your heating
requirements.
