Vaillant Vantage 150 - Technical Data

Vantage Vantage Vantage Unit
120 150 200
Nominal storage capacity 120 150 200 litres
Nominal DHW flow from
VANTAGE 120/150 15 l/min @ 60 °C
VANTAGE 200 20 l/min @ 60 °C
Maximum water supply pressure 10 bar
Maximum primary circuit pressure 2.5 bar
Expansion vessel charge pressure 4 bar
Operating pressure 3.5 bar
Net weight 70 82 101 kg
Weight (full) 190 232 301 kg
Cylinder connections:
Cold mains inlet 22 mm compression
D.H.W. outlet 22 mm compression
Balanced pressure cold water outlet 22 mm compression
Secondary return G
3
/
4
Primary flow 22 mm compression
(on 3 port valve)
Primary return 22 mm compression
Electrical connections:
3 kW Immersion heater 230/240 V, 50 Hz
Three port valve 230/240 V, 50 Hz
Cylinder thermostat 230/240 V, 50 Hz
Technical data 2
Vaillant Vantage 120/150/200 5
2 Technical data
