Vaillant VRT 350f - Overview of the Equipment; Unit Design

3 Overview of the equipment
8 Operating instructions VRT 350f 0020131979_00
3 Overview of the equipment
3.1 Unit design
Radio controller
1
3
2
6
5
4
7
1 Display
2 Wall-mounting base
3 Diagnostics socket
4 Wall-mounting base cover
5 Right-hand selection
button
6 Rotary knob
7 Left-hand selection button
Radio receiver unit
2
4
3
1
1 Wall-mounting base
2 Diagnostics socket
3 LED
4 Teach-in button
