Vaisala HUMICAP TMW92 User Manual

Chapter 2 ___________________________________________________________ Product Overview
VAISALA ________________________________________________________________________ 15
1201-005
Figure 3 Opening the Transmitter
where
1
=
Push tab down with a screwdriver to open the transmitter.
To open, use a screwdriver to push down the tab that holds the
transmitter cover and mounting base together. Pull the mounting base
away from the cover, starting from the top.
To close, connect the bottom of the transmitter first, and tilt the top
forward to close the tab. Do not push on the display. Closing the
transmitter starts it up if power is supplied to the screw terminals.
CAUTION
When opening or closing the transmitter, avoid damaging the transmit
ter
electronics with the two plastic supports on the mounting base.
See
Figure
4 on page 16 and Figure 5 on page 17.
1

Vaisala HUMICAP TMW92 Specifications

General

Brand	Vaisala
Model	HUMICAP TMW92
Category	Temperature Controller
Language	English
