Val Controls I 24-BF Series User Manual

DHP-UM-013
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600 • Fax +45 7547 0611
vc@valcontrols.com • www.valcontrols.com
Revision: 4
23/58
Length: 1 bytes
Read Write
2: Alarm State
Length: 1 bytes
Read Only
3: Time Stamp
Length: 8 bytes
Read Only
4: Sub code
Length: 2 bytes
Read Only
5: Value
Length: 1 bytes
Read Only
Description: The block alarm is used for all
configuration hardware connected failure or
system problems in the block. The cause of the
alert is entered in the sub code field.
ALARM_SUM
[Others]
37
1: Current
Length: 2 bytes
Read Only
2: Unacknowledged
Length: 2 bytes
Read Only
3: Unreported
Length: 2 bytes
Read Only
4: Disabled
Length: 2 bytes
Read Write
Value: 0x0000
Description: The current alert status,
unacknowledged states, unreported states, and
disabled states of alarms associated with function
block.
ACK_OPTION
[Alarms]
38
Length: 2 bytes
Read Write
Value: 0x0000
