Val Controls I 24-BF Series User Manual

DHP-UM-013
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600 • Fax +45 7547 0611
vc@valcontrols.com • www.valcontrols.com
Revision: 4
26/58
4: Sub Code
5: Value
Description: The block alarm is used for all
configuration hardware connected failure or system
problems in the block. The cause of the alert is
entered in the sub code field.
TRANSDUCER_TYPE
[I/O Cfg]
Description: Identifies the transducer that follows
XD_ERR
[Diagnostic]
Description: On of the transducer error code defined
in the FF Transducer specifications
SENSOR_TYPE
[I/O Cfg]
Description: The type of sensor
Value: NonStdSnsr
MEDIA
[Others]
Media
Value: RS232
Description: Internal communication settings
between Val Controls product and fieldbus
interface. Do not change
BAUD_RATE
[Others]
Baud Rate
Default Value:38400
Description: Internal communication settings
between Val Controls product and fieldbus interface
in Val Controls product. Do not change
STOP_BITS
[Others]
Stop Bits
Value: One Stop Bit
Description: Internal communication settings
between Val Controls product and fieldbus
interface. Do not change
PARITY
[Others]
Parity
Value: Even
Description: Internal communication settings
between Val Controls product and fieldbus
interface. Do not change
CRC_ORDER
[Others]
CRC Order
Value: Normal
Description: Internal communication settings
between Val Controls product and fieldbus
interface. Do not change
TIME_OUT
[Others]
Time Out
Value: 300mSek
Description: Internal communication settings
between Val Controls product and fieldbus
interface. Do not change
NUMBER_OF RETRY
[Others]
Number of Retry
Value: 5
Description: Internal communication settings
between Val Controls product and fieldbus
interface. Do not change
SLAVE_ADRESS
[Others]
Slave Address
