Val Controls I 24-BF Series User Manual

DHP-UM-013
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600 • Fax +45 7547 0611
vc@valcontrols.com • www.valcontrols.com
Revision: 4
32/58
Status – Sub status: Non Specific ..
Status – Limits: Not Limited
Description: Discrete Input from sensor in
valcontrols product
LOC_IN_D1
[Others]
LOC_IN_D1
Value Data Type = Unsigned8_0
Value Function Code = FC03 Reading Holding
Register
Value REGISTER_ADDR_OF_VALUE = 7020
Value REGISTER_ADDR_OF_STATUS = 7120
Description: Internal communication settings
between valcontrols product and fieldbus interface.
If input is not used set
REGISTER_ADDR_OF_STATUS = 0, Status sub
status then changes to “Out of Service”
MOD_IN_D2
[Others]
Same as MOD_IN_D1
LOC_IN_D2
[Others]
Same as LOC_IN_D1
Value REGISTER_ADDR_OF_VALUE = 7021
Value REGISTER_ADDR_OF_STATUS = 7121
MOD_IN_D3
[Others]
Same as MOD_IN_D1
LOC_IN_D3
[Others]
Same as LOC_IN_D1
Value REGISTER_ADDR_OF_VALUE = 7022
Value REGISTER_ADDR_OF_STATUS = 7122
MOD_IN_D4
[Others]
Same as MOD_IN_D1
LOC_IN_D4
[Others]
Same as LOC_IN_D1
Value REGISTER_ADDR_OF_VALUE = 7023
Value REGISTER_ADDR_OF_STATUS = 7123
MOD_IN_D5
[Others]
Same as MOD_IN_D1
LOC_IN_D5
[Others]
Same as LOC_IN_D1
Value REGISTER_ADDR_OF_VALUE = 7024
Value REGISTER_ADDR_OF_STATUS = 7124
MOD_IN_D6
[Others]
Same as MOD_IN_D1
LOC_IN_D6
[Others]
Same as LOC_IN_D1
Value REGISTER_ADDR_OF_VALUE = 7025
Value REGISTER_ADDR_OF_STATUS = 7125
MOD_IN_D7
[Others]
Same as MOD_IN_D1
LOC_IN_D7
[Others]
Same as LOC_IN_D1
Value REGISTER_ADDR_OF_VALUE = 7026
Value REGISTER_ADDR_OF_STATUS = 7126
MOD_IN_D8
[Others]
Same as MOD_IN_D1
LOC_IN_D8
[Others]
Same as LOC_IN_D1
Value REGISTER_ADDR_OF_VALUE = 7027
Value REGISTER_ADDR_OF_STATUS = 7028
MOD_OUT_D1
[Others]
MOD_OUT_D1
Value: State 0 .. 255
Value Status: Good, Bad ..
