DHP-UM-013
Val Controls A/S Limfjordsvej 3 DK-6715 Esbjerg N Tel. +45 7547 0600 Fax +45 7547 0611
vc@valcontrols.com www.valcontrols.com
Revision: 4
35/58
Length 1 byte
Read Write
Description: The common mode for the Actual target
BLOCK_ERR
[Diagnostic]
6
Length 2 byte
Read Only
Description: This parameter reflects the error status
associated with the hardware or software components
associated with a block. It is a bit string, so that
multiple errors may be shown.
PV
[Process]
[Trends]
7
1: Process Variable
Length 4 byte
Read Only
Description: The process variable read from the
hardware, addressed in the Modbus Transducer block
2: Process Variable Status
Length 1 byte
Read Only
The process variable status
OUT
[Process]
8
Length 4 byte
Read Only
Description: The block output value calculated as a
result of the block execution.
SIMULATE
[Options]
9
1: Simulate Status
Length 1 byte
Read Write
2: Simulate Value
Length 4 byte
Read Write
3: Current Transducer Status
Length 1 byte
Read Only
4: Current Transducer Value
Length 4 byte
Read Write
5: Simulation Enable/Disable bit
Length 1 byte
Read Write
Description: Allows the transducer analog input or
