15
EN
Using the appliance
B
NOTE
Depending on where your electrical outlet is, you may need
to cut a hole in the opposite cabinet side.
Step 2. Aesthetic panel’s dimensions and installation
NOTE
Follow the specific installation instruction for attaching the
aesthetical door panel.
Semi-integrated model
• Seperate velcro stripe
A
and velcro stripe
B
and attach velcro stripe
A
on the inner side
of the aesthetic panel. Attach the felted velcro stripe
B
on the outer door of dishwasher (see
figure
A
). After positioning of the panel, fix the panel onto the outer door by screws and bolts
(See figure
B
).
A B
Velcro stripe
Velcro stripe
1.Take away the four short screws
2.Pin up the four long screws
