Using the appliance
B
Fully-integrated model
• Install the hook on the aesthetic panel and put the hook into the slot of the outer door of
dishwasher (see figure
A
). After positioning of the panel, fix the panel onto the outer door
by screws and bolts (See figure
B
).
A B
1.Take away the four short screws
2.Pin up the four long screws
Step 3. Tension adjustment of the door spring
1. The door springs are set at the factory to the proper tension for the outer door. If aesthetic
panel are installed, you will have to adjust the door spring tension. Rotate the adjusting
screw to drive the adjustor to strain or relax the steel cable.
2. Door spring tension is correct when the door remains horizontal in the fully opened
position, yet rises to a close with the slight lift of a finger.
