Valcom V-9970 - One Zone Connections Location of Screw Terminals, Option Switches and Music Volume Control

5
8 7 6 5 4 3 2 1OFF
ON
R13
Music
Volume
J2
12V
IN
COM 24V
Power On LED
LED designates
page in process
VP-412A
Power
Supply
Connection made
via an RJ11C jack
24V Option
(If used)
Dipswitches (shown with Default Settings)
(Refer to Chart for actual times)
Up to 150 Valcom
Amplified Speakers
Line Level
Music
Source
FIGURE 1 - ONE ZONE CONNECTIONS
LOCATION OF SCREW TERMINALS,
OPTION SWITCHES AND MUSIC VOLUME CONTROL
SW1
J1
SW2
-24VDC
Power
Supply
+
Incoming Telephone
Line or PABX Station
OR
- +
COM SIG
MUSIC IN
USER
CONTACT
PAGE OUT
