Valcom V-9972 Configuration Guide

www.valcom.com
I
540.563.2000
I
800.825.2661
®
Wiring Connections
Page 23
Connections to Multi-Zone Controllers
Connections to Self-Amplified Speakers or External Amplifier
Low
Level
Music
Source
Low
Level
Music
Source
-24VDC
POWER
SUPPLY
EXTERNAL
AMPLIFIER
SELF-AMPLIFIED
HORN/SPEAKER
ANALOG TELEPHONE OR
PBX TRUNK PORT
(DIP SWITCH SW6 ON)
ANALOG TELEPHONE OR
PBX TRUNK PORT
(DIP SWITCH SW6 ON)
FXS PORT OR
PBX STATION PORT
(DIP SWITCH SW6 OFF)
FXS PORT OR
PBX STATION PORT
(DIP SWITCH SW6 OFF)
T R
RELAY
OR
OPTIONAL
Optional
T/R Input
Music Input
One-Way or Talkback
Valcom Zone Controller
V-2003A, V-2006A, V-ACS, Etc.
(Battery Feed Switch On)
VP-624
Power
Supply
Other
-24VDC
Power
Supply*
* May be provided
by Page Control
or
+ —
VP-624
Power
Supply
Other
-24VDC
Power
Supply*
* May be provided
by Page Control
or
+ —
OR
OR
OR
