SMART HATCH
16
3.2.2. Make note of all the parts that
should be included for the installation.
3.2.3. Exterior installation - Remove
backing tape from butyl seal. In-
sert the hatch through the roof open-
ing diagonally and place the bottom
of the frame on the roof surface.
NOTES
Surfaces must be clean and dry to ensure proper sealing of
butyl tape on bus roof. Application temperature range for
butyl is +50ºF to +125ºF (+10ºC to +52ºC).
(Photo 16: SMART Hatch Assembly)
(Photo 17: SMART Hatch Assembly)
