SMART HATCH
25
6.3. Spare/ Replacement Parts
Part Number Discription Quantity
11135687A Dome Assembly 1
11135688A Screw (for Mechanism Tube) 2
11135944A Weather Seal 1
11135945A Mechanism Assembly 1
11135938A Spring Plunger 1
11135949A Bolt (for Frame) 1
11135946A Microswitch and Cable 1
11136389A Inner Handle 1
11135947A Mechanism Tube 1
11136388A Outer Handle 1
11136301A Outer Handle Gasket 1
11136308A Inner Trim Ring 1
11135948A Knob Assembly 1
(Table 2: Smart Hatch Spare Parts)
