Valeo SMART - Technical Data; The Technical Data for the Smart Roof Hatch Are Listed in Table

SMART HATCH
23
5. Technical Data
5.1. The technical data for the Smart
roof hatch are listed in Table 1.
Panel Size 700 x 700 mm (27.6 x 27.6 in.)
Egress Opening Size 552 x 466 mm (21.7 x 18.1 in.)
Opened Height 134 mm (5.3 in.)
Closed Height 38 mm (1.5 in.)
Weight 5 kg (11 lbs.)
Materials Plastic, Steel and Aluminum
Roof Radius Range 3,000 to 23,000 mm (118.1 to
905.5 in.)
Roof Thickness Range 35 to 70 mm (1.4 to 2.7 in.)
Roof Cut-Out, min. /
max.
597 mm (23.5 in.) / 616 mm
(24.25 in.)
Temperature Range -40º to 85ºC (-40º to 185ºF)
(Figure 3: SMART Hatch Dimen-
sions)
