SMART HATCH
20
3.2.10. Attach bottom cover to roof
of bus with (8) #8 x 1 long self-drilling
pan head sheet metal screws.
3.2.11. Remove TO FRONT OF VEHICLE sticker.
NOTES
The interior trim ring was designed to work with roof thick-
nesses between 1.4 inch to 2.7 inches. Heights above or
below this range will result in gapping or interference with
the frame Modifications for fitment are the responsibility of
the installer.
(Photo 24: SMART Hatch Assembly)
(Photo 25: SMART Hatch Assembly)
