18
Connecting Water Block to the
Motherboard
1. Insert TF Card.
2.Connect the water pump 4PIN connector into the AIO_PUMP header on
the motherboard.
3. Connect water block LCD to the USB connector on the motherboard.
AIO_PUMP CPU_FAN
AIO_PUMP
RGB
USB 2.0
ARGB
1
2
3
MOTHERBOARD
EN
