Valkyrie HUB Wiring
1. Plug the SATA power supply connector into the Valkyrie HUB POWER port.
2. Plug the 4PIN fan connectors and ARGB connectors into the Valkyrie HUB,
respectively.*
3. Connect Valkyrie HUB control cables to MB_FAN and MB_ARGB ports
respectively and plug the other ends into the CPU_FAN and AGRB headers on
the motherboard.
*The FAN_01 (red) on the VK HUB7 must be plugged in with a 4PIN fan connector.
