Vallox 95 User Manual

VALLOX 75/95
4
CONTROL METHODS
In winter use the heat recovery cell of VALLOX 75 and VALLOX 95 recovers heat from the
air leaving the dwelling and uses it to heat the air coming from the outside.
Electric radiator
VALLOX 75 / 95 units feature a 500 W post-heating radiator.The temperature of supply
air is adjusted at the thermostat regulatorlocated inside the unit.Adjustments can be made
within the range of 0...25°C.
POST-HEATING
In summer use the heat recovery cell is bypassed in VALLOX 75 and VALLOX 95 with anin-
built damper.
In the summer position airflow through the cell is prevented, and heat recovery bypass is
activated.
REMOTE MONITORING CENTRE VALLOX 1993 A
• ON/OFF switch
• Operating status data to remote monitoring
• Transformer with eight voltage options,
of which two + one preselected
• Can be controlled with a timer or through
remote monitoring, for example.
Depth: 100 mm
Height: 180 mm
Width: 255 mm
SEPARATE CONTROL CENTRE 1992A 0.85 A
Depth: 90 mm
Height: 140 mm
Width: 110 mm
• 4-step adjustment
• ON/OFF switch
SEPARATE CONTROL CENTRE 1992A EK 0,85 A
Depth: 90 mm
Height: 140 mm
Width: 110 mm
• Separate 4-step adjustment switch
• ON/OFF switch
COOKER HOOD X-LINE PTX/PTXP(A) 500/600 0,85 A
Depth: 500 mm
Height: 140 mm
Width: 498/598 mm
• Washable grease filter, easy to remove
• Bright, long lasting fluorescent lamp
• Outlet collar with rubber ring
HEAT RECOVERY BYPASS

Vallox 95 Specifications

General

Brand	Vallox
Model	95
Category	Fan
Language	English
