5
1.4.3 Press the Pressure & Temp. Switch to change the time value.
1.4.4 You must press the Axle Switch for 8 seconds to exit time setting mode, if not, the
time setting will not come into effect. A sound “DI” will follow the normally exit.
1.5 Low Pressure Warning
When current pressure in the tyre is 20% lower than baseline pressure: ①Display shows
the pressure of axle with abnormal tyre; ②Warning sound “Di-Di”; ③Abnormality icon
“ ” appears; ④The digits of abnormal tyre position twinkle.
The figure above shows “1B” tyre and ”2A” tyre are under-inflated. The display just shows
axle1 and axle2 automatically and circularly until the problems are corrected.
1.6 High Pressure Warning
When current pressure in the tyre is 30% higher than baseline pressure: ①Display shows
the pressure of axle with abnormal tyre; ②Warning sound “Di-Di”; ③Abnormality icon
“ ” appears; ④The digits of abnormal tyre position twinkle.
