VALPRO VP29S-HC - Page 13

Service and Installation Manual
For warranty service, call 1-888-VALPRO8 / 1-813-502-0300 13
WIRING DIAGRAM
MODEL: VPP47
MODEL: VPP71
PLUG
THERMOSTAT DISPLAY
CONDENSER
FAN MOTOR
OVERLOAD
PROTECTOR
COMPRESSOR
PTC STARTER
CIRCUITALION
FAN MOTOR
t ℃
L
N
ROOM
EVAP
SENSOR
DOOR FRAME HEATER
MM
L
N
THERMOSTAT DISPLAY
PLUG
CIRCUITALION
FAN MOTOR
OVERLOAD
PROTECTOR
COMPRESSOR
ROOM
EVAP
SENSOR
DOOR FRAME HEATER
MIDDLE FRAME HEATER
CONDENSER
FAN MOTOR
STARTING
CAPACITOR
CURRENT
RELAY
