Ideally, two drums, each with capacity for a
week of fuel, should be used. After filling, the
oil must rest for two to three days for the
impurities settle to the bottom. Thus, while one
rests, the other is being used. If larger tanks
are used, there must be an upper cover (1) for
cleaning, at least 40 mm in diameter.
The point for filling the tank (2) should be easily
accessible and at least 65 mm in diameter. If
there is a tube, it should end 15 cm from the
bottom and may be equipped with a filter. The
end cap should be the same as that used in
vehicle tanks.
A vent with a minimum diameter of 80 mm and fitted with a protective filter (5) should be installed in
the upper part of the tank.
The vehicle filling outlet (3) must be installed on the higher side of the drum, 80 mm from the bottom.
Post clearly visible signs with the words:
DANGER:
Flammable - No smoking
IMPORTANT: Follow the maintenance procedures to keep the equipment in good condition.
GUID-0FE6267B-4174-4E1B-99C4-7696F76AF4F5-high.jpg [High]
Fig. 3
1. Safety
BH Generation 4 15
ACW1530770
