GUID-5F1247BB-4AFE-4B0B-8FFC-60D3175EC97E
1. Power shuttle lever
2. Powershift preprogramming push button
3. Proline instrument panel
4. Main switch (extra equipment)
5. Hazard warning flasher switch
6. Light switch
7. Proline instrument panel display change-over switch
8. Proline instrument panel display setting switch
9. Upper headlights (extra equipment)
10. Multifunctional lever
11. Ignition switch
12. Lever for adjusting steering wheel position
13. Electric centre, lower part of the dashboard
14. Steering wheel
15. A-pillar display
2.2.1 Proline instrument panel
The operator receives information from the gauges, coolant thermometer,
tachometer, speedometer and indicator lights. All this can be seen on the Proline
instrument panel.
2. Instruments and controls
- 22 -
