ValueHD VHD-V61 - Detailed Product Specifications; Video and Audio Coding; Stream Resolutions and Bit Rates; Supported Network Protocols

ValueHD Corporation
10
Video coding standard
H.265/H.264
Video Stream
Main stream, Sub stream
Main stream resolution
1920x1080, 1280x720
Sub stream resolution
720x480, 320x240
Bit Rate
128K,256K,384K,512K,768K,1024K,1536K,2048K,3072K,4096K,5120K,6144K,8192K
Bit Rate Type
Variable rate, Fixed rate
Maximum Frame
PAL:1-25, NTSC:1-30.
Audio encode standard
AAC
Audio stream rate
96K, 128K, 256K
Support protocols
TCP/IP, HTTP, DDNS, RTSP, RTMP, PPPoE, SMTP, UPnP, SNMP, FTP(Optional)
Input/Output Interface
HD Output
1xHDMI: Version 1.3
1x3D-SDI: BNC type, 800mVp-p, 75Ω, Along to SMPTE 424M standard
SD Output
1xCVBS: RCA jack, 1Vp-p, 75Ω
Network interface
1xRJ45: 10M/100M Adaptive Ethernet ports
Audio Input
1-ch 3.5mm audio interface, Line In
USB
1xUSB2.0: type A jack
Communication interface
1xRS-232 IN: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA/Pelco-D/Pelco-P
1xRS-232 OUT: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA network use only
1xRS-485: 2pin Phoenix Port, Max Distance: 1200m, Protocol: VISCA/Pelco-D/Pelco-P
Power jack
JEITA type (DC IN 12V)
Generic Specification
Input Voltage
DC 12V
Current Consumption
1.0A (Max)
Operating Temperature
-5°C ~ 40°C
Storage Temperature
-20°C ~ 60°C
Power Consumption
12W (Max)
