A list of detected expanders and any associated PSUs is displayed.
Expander ID This ID number is a unique identifier for the expander.
Description Text description of the expander. This text will also appear on the browser and keypad.
Type The type of expander detected (I/O, PSU, keypad, etc.).
S/N The serial number of the expander.
Version The firmware version of the expander.
Comms The status of the expander (online or offline).
Status The status of the expander (OK, Fault, OP Tamper).
PSU The type of PSU that is fitted to the expander, if applicable. Click the PSU to view the PSU status.
Performable actions
Refresh Click the button to update the status of the X-BUS.
To view more status information:
l Click any of the expander’s identifying parameters (ID, description, type, serial number) to display
further status details.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 181 A6V10276959-d
11.2018
