12
7.1 Check both sides of the front fork
dropout to see if the installation
is correct, the anti-theft nut should sit
in the center of the dropout.
8.2 To connect the motor cable, both
arrows should be aligned (C). Then,
tuck the motor cable into the front fork
as far as possible (D).
8.1 Make sure that the motor cable (A) runs
between the motor and fender stay (B).
7. Wheel alignment
8. Connect the motor cable
CA
B
D
Installation correctInstallation incorrect
