Vantec UGT-PCE2S1P User Manual

UGT-PCE2S1P Page 4
System Requirements
 Windows® XP/Vista/7/8 (32/64 bit)
 PCI Express-enabled system with an available PCI Express slot
Package Contents
 1 x 2-Serial/1-Parallel Port PCIe Adapter
 1 x Bracket with two DB9 male serial ports
 3 x Low profile brackets
 1 x User Manual
 1 x Driver CD
Hardware Installation
1. Turn off the power to your computer.
2. Unplug the power cord and remove your computer’s cover.
3. Remove the screw and slot bracket from an available PCIe slot.
4. To install the card, carefully align the card’s bus connector with
the selected PCIe slot on the motherboard. Push the board down
firmly.
5. Replace the slot bracket’s holding screw to secure the card.

Vantec UGT-PCE2S1P Specifications

General

Brand	Vantec
Model	UGT-PCE2S1P
Category	Adapter
Language	English
