Vespera Instruction Manual v1.2 EN 2022-06 8
Vespera AC021 Solar Filter
1. never point Vespera at the sun without a Vaonis solar filter installed
2. ensure the product is level
3. only handle the filter by its edge to avoid dirtying or damaging it
4. an "alert" window may appear:
if the instrument detects too much light, the observation will be interrupted for safety
reasons. Ensure the filter is properly positioned
if the instrument detects the solar filter was removed, the observation will be
interrupted for safety reasons. Ensure the filter is properly positioned
Installing the filter
1. Turn the product on.
2. Connect to Vespera via the Singularity application.
3. In the application, go to the "space center" page.
4. Click on Solar Pointing
for the first observation, read the information, then press Close
5. Select your observatory.
6. Press the start button: the arm will open to 90°.
7. Remove the cover located on the front end of the optical arm by pressing the button provided for
that purpose.
8. Position the AC021 solar filter.
9. If properly assembled
a filter icon and the name of the filter, "SOLAR", will appear under the product image
press the "confirm filter installation" button
follow application instructions to properly position the instrument
press the "confirm arm orientation" button for Vespera to start the solar observation
10. If improperly assembled or defective
the "confirm filter installation" button will not be available (dimmed)
the filter icon will not appear under the product image, "no filter detected" will appear instead
remove the filter and reassemble. If the problem persists, contact support
