AIR NOZZLE, FLUID TIP, NEEDLE ASSEMBLY
TToo pprreevveenntt ddaammaaggee ttoo tthhee fflluuiidd ttiipp oorr fflluuiidd nneeeeddllee,, bbee ssuurree
ttoo eeiitthheerr:: 11)) ppuullll tthhee ttrriiggggeerr aanndd hhoolldd wwhhiillee ttiigghhtteenniinngg oorr
lloooosseenniinngg tthhee fflluuiidd ttiipp,, oorr 22)) rreemmoovvee fflluuiidd nneeeeddllee aaddjjuussttiinngg ssccrreeww ttoo rreelliieevvee sspprriinngg
pprreessssuurree aaggaaiinnsstt nneeeeddllee ccoollllaarr..
1) All nozzles and needles are precision made and should be handled with care.
2) Except as described in “Fluid Needle Adjustment”, do not make any alterations in
the gun. To do so will cause finishing difficulties.
3) To clean nozzles, soak them in solvent to dissolve any dried material, then blow
them clean with compressed air.
4) Do not probe any of the holes in the nozzles with metal instruments. If probing is
necessary, use only a tool that is softer than brass.
FLUID NEEDLE ADJUSTMENT
1) Loosen the needle cap.
2) Screw the needle assembly locknut out for more trigger movement, in for less
trigger movement.
3) Adjust the needle assembly so that when the trigger moves, the air valve assembly
moves 1/16” to 3/32” before the needle assembly moves.
4) Tighten the needle cap.
OOvveerr ttiigghhtteenniinngg mmaayy ddaammaaggee tthhee tthhrreeaaddss,, wwhhiicchh wwiillll mmaakkee
ffuuttuurree aaddjjuussttmmeennttss ddiiffffiiccuulltt..
O-RINGS, SEALS, AND PACKING NUTS
1) Check and replace any damaged 0-rings and seals. O-rings and seals can be wiped
clean but not soaked in solvent.
2) Unscrew packing nuts and replace the packing ONLY if a leak will not stop when
the nut is tightened. Do not over tighten a packing nut as this will restrict
movement of the needle.
3) Reassemble in reverse order of above and use light machine oil to lubricate
moving parts.
STORAGE
1) When not in use, tur
n the fluid adjustment knob counter
-clockwise to open to
r
educe the spring tension on the needle fluid tip.
2) Spray gun
mmuusstt bbee
cleaned and lightly lubricated prior to storage.
14 15
4) Clean gaskets with solvent soaked rag. To prevent damage, do not immerse gas-
kets or spray gun in solvents as this is detrimental to the lubricants and packings.
5) After using water to clean out water based paints or materials, spray mineral spirits
through the gun to prevent corrosion.
6) Lubricate gun after cleaning using light machine oil.
NNeevveerr uussee lluubbrriiccaannttss ccoonnttaaiinniinngg ssiilliiccoonnee aass tthheessee lluubbrrii--
ccaannttss ccaann ccaauussee ffiinniisshh ddeeffeeccttss..
Apply light machine oil to: fluid needle packing, air valve packing, side port control
packing, and trigger point. Coat fluid control spring and all threaded connections with
petroleum jelly prior to storage.
CLEANING SPRAY GUNS USED WITH PAINT TANKS
SShhuutt ooffff aaiirr ssuuppppllyy ttoo ppaaiinntt ttaannkk aanndd rreelleeaassee pprreessssuurree iinn
tthhee ttaannkk
1) Open the vent on the paint tank. If using an external mix cap, loosen cap slightly.
2) Reduce air pressure to 10 to 20 PSI. Hold a wadded piece of cloth over the tightly
around the air cap opening(s) and pull the trigger. Air will back up thorough the
fluid nozzle and force fluid out of the hose and back into the tank.
3) Pour paint from the tank and clean tank with solvent and rags.
4) Pour enough thinner into the tank to clean the hose and gun thoroughly. Close the
tank and spray from the gun until the solvent comes out clean.
5) Remove fluid hose and blow it out thoroughly to remove all traces of solvent in the
hose.
WWhheenn bblloowwiinngg oouutt tthhee hhoossee,, tthhee ooppeenn eenndd sshhoouulldd bbee aaiimmeedd
aawwaayy ffrroomm aannyy ppeerrssoonn ttoo aavvooiidd bblloowwiinngg ssoollvveenntt iinnttoo tthhee
eeyyeess oorr oonn tthhee sskkiinn ccaauussiinngg ppoossssiibbllee iinnjjuurryy..
