Vaporesso LUXE XR MAX User Manual

USE INSTRUCTIONS
Dimensions: 106.5 x 32.1 x 26 mm
POD Capacity: 5ml/2ml(TPD)
Compatible POD:
LUXE X 0.4Ω MESH POD
LUXE X 0.6Ω MESH POD
LUXE X 0.8Ω MESH POD
LUXE XR DTL POD
LUXE XR RDL POD
LUXE XR MTL POD
Battery Capacity: 2800mAh
Output Power: 80W
Charging Current: DC 5V/2A,Type-C
Display: 0.54’’ OLED Screen, 2 * RGB LED Light
1. Fill E-liquid
- Take out the used POD from the battery
and pull out the silicone plug from the
bottom of the POD;
- Fill e-liquid through the hole
- Put the silicone plug back in place rmly
after lling is nished.
- Please wait 5 minutes for the e-liquid to
soak into the coil completely.
* Refer to the gure 1 above.
2. Replace the Coil
- Take out the POD from the battery;
- Pull out the used coil from the POD;
- Install a new coil to the POD;
- Reattach the POD into place.
* Refer to the gure 2 above.
3. Adjust the Airow
There is an airow control toggle on the side
of the battery. Adjust the toggle according
to your vaping habits for different airow
effects.
* Refer to the gure 3 above.
4. Power on/off the Device
Click the power button 5 times in 2 seconds
to power on or off the device.
5. Start Vaping
Press the power button to enjoy extraordinary
vaping experience.
1 x VAPORESSO LUXE XR MAX Battery
1 x VAPORESSO LUXE XR POD (DTL)
1 x VAPORESSO LUXE XR POD (RDL)
1 x GTX 0.2Ω MESH COIL
1 x GTX 0.4Ω MESH COIL
1 x TYPE-C Cable
1 x User Manual & Warranty Card
1 x Reminder Card
SPECIFICATION
PACKING LIST
6. Setting
1) Main interface
When the screen is activated, the screen
will display the battery level, wattage and
puff number from top to bottom when not
vaping, the puff number will turn to vaping
time during vaping.
2) Adjust wattage
Click the power button 3 times in 2 seconds
to unlock the touch adjustment button then
you can adjust the wattage.
Click the power button 1 time to conrm the
wattage you choose and back to the main
interface.
3) Recommended Power Adjustment
LUXE XR MAX Kit is using the GTX coil
platform, and the suggested power need to
be noticed before start vaping.
4) Entering the menu
Click the power button 4 times in 2 seconds
to enter the menu, press touch button “^”
or “v” to switch between different functions
settings, click the power button 1 time to
conrm the function to set, then you can:
①
turn on or off the led light
②
turn on or off the smart mode
*Smart mode: When this function is turned
on and a new POD is installed, the system
will adjust to the best power, and conne the
power in the recommended range.
③
clear the puff number
④
back to the main interface
* Refer to the gure 4 above.
7. Battery Level
8. Charge the Battery
After connecting the Type-C cable to the
battery, the battery indicator and remaining
charging time will be showed on the screen.
9. Safety Mode
If the vaping time over 10 seconds, the
battery level LED light quick ash 5 times and
the device will be powered off automatically,
press power button 5 times constantly to
power on again.
GTX MESH
COIL
GTX 0.2Ω
MESH
GTX 0.4Ω
MESH
Suggested
Wattage
45-60W 26-32W
LED Battery Status
Green-cyan 60%-100%
Cyan-blue 30%-60%
Blue-rose red 0%-30%

Vaporesso LUXE XR MAX Specifications

General

Battery Capacity	2800mAh
Output Power	80W
Pod Capacity	5ml
Adjustable Airflow	Yes
Charging Port	USB Type-C
Charging Current	5V/2A
Coil Compatibility	GTX Coils
Coil Resistance	0.2Ω
Colors	Black, Silver, Blue, Red
Dimensions	106mm x 32mm x 26mm
