1 Ventilation
2 [AUTO] | The LED lights up blue when an automatic show is running.
3 [DMX] | The LED lights up red if DMX is connected.
4 LED display
5 [MENU] | Activates the main menu and switches between menu items. Closes an open submenu.
[UP] | Increases the displayed value by one.
[DOWN] | Decreases the displayed value by one.
[ENTER] | Selects an option of the respective operating mode, conrms the set value.
6 [SLAVE] | The LED lights up yellow if the device is in “slave” mode.
7 [SOUND] | The LED lights up green when sound control is active.
8 [POWER] | IEC chassis plug with fuse holder for power supply
9 [DMX IN] | DMX input
10 [DMX OUT] | DMX output
11 Safety cable eyelet
12 USB port for rmware updates
13 [MIC] | Microphone for sound control
Connections and controls
