8 Technical specications
Laser medium Red: 650 nm
Green: 532 nm
Laser power Red: 100 mW
Green: 30 mW
Laser class 2M
Light source Derby eect: 4 LEDs (1 × red, 1 × green, 1 × blue, 1 × white),
30 W each
16 × RGB strobe LEDs, 0.5 W each
Control DMX
Buttons and display on the device
IR remote control
Number of DMX channels 2 or 9
Input connections Power supply IEC chassis plug C14
DMX control XLR chassis plug, 3-pin
Output connections DMX control XLR chassis socket, 3-pin
200 mm
142 mm
185 mm
214 mm
Technical specications
Razor Derby
37
LED Eect
