4
unfolding handle / filling the solution tank
3. Carpet Cleaner Basics
Unfold handle
Raise handle from storage position until it locks in place
(Fig.3/1).
Slide collar (A) up on telescoping handle (B) to adjust
handle to desired height (Fig.3/2).
Folding handle
Push up on the collar (A) to lower the telescoping handle.
Rotate knob (C) backwards to drop the handle into storage
position (Fig.3/3).
Filling the Solution Tank
IMPORTANT: Unplug carpet cleaner from electrical outlet.
Pull up on solution tank handle (A) and remove solution
tank (Fig.3/4).
Turn tank upside down and unscrew cap (B) (Fig.3/5). The
cap consists of 2 pieces - the cap ring (C) and the solution
tank valve (D).
Pour solution into tank to solution fill line (E) (Fig.3/6).
Fill tank completely with hot tap water (max 50°C).
Replace cap. Be sure the valve (D) is in the cap ring (C)
before screwing the cap back on the tank (Fig.3/5).
Place tank back onto cleaner (Fig.3/7), pressing firmly to
be sure tank is fully positioned.
CAUTION: Avoid solution contact with the eyes and
skin. In case of contact with eyes, flush with cold
water for 15 minutes. In case of contact with skin, wash
with water. If irritation persists, consult your GP.
!
Fig.3/1
Fig.3/4
Fig.3/2
Fig.3/5
Fig.3/6
Fig.3/3
B
C
A
A
A
B
C
D
E
