www.vax.co.uk
6
hose and tools
4. Hose and Tools
Using the Hose
Place handle in upright, storage position.
Press on the tab (A) to remove the hose wand (B) from the
floor nozzle (C) (Fig.4/1).
Attaching Tool
Stair/upholstery nozzle has a built-in brush to help
provide the scrubbing action some spots may need for
removal (Fig.4/2).
Slide tool (D) onto end of hose wand. Snap tool over bump
(E) on wand (Fig.4/3).
Removing Tool
To remove tool: Push forward and up on tab (F). Slide tool
off hose wand.
Storing Hose and Tool
To return hose wand to storage position, align bump (E) on
wand with hole (G) in nozzle and push in firmly until you
hear a snap (Fig.4/4).
NOTE: Hose wand must be returned to floor nozzle
storage position in order for cleaner to be used in the
upright position for floor cleaning.
Store upholstery nozzle (H) over projection (I) on back of
cleaner for storage (Fig.4/5).
Fig.4/2
Fig.4/3
Fig.4/1
Fig.4/4
Fig.4/5
A
C
D
F
E
B
E
G
H
I
Vax V-128 User Guide.qxd:V-128 User Guide 14/4/08 16:01 Page 6
